29
REPLACEMENT PARTS LIST
For replacement parts, call our customer service department at 1-877-447-4768, 8:00 a.m. – 4:30 p.m.,
CST, Monday – Friday.
PART DESCRIPTION PART #
1 Temp gauge assembly 70-02-577
2 Door handle 70-02-036
3 Badge 70-10-540
4 Lid handle assembly 70-01-907
5 Lid pivot pin-with cotter pin 70-01-641
6 Lid assembly 70-02-037
7 Lid bumper 70-01-176
8 Warming rack 70-01-909
9 Cooking grate for main burner 70-01-910
10 Cooking grate for sear burner 70-01-911
11 Heat tent for main burner 70-02-411
12 Heat tent for SearPLUS™ burner 70-02-412
13 Main burner with cotter pin 70-02-038
14 SearPLUS™ burner with cotter pin 70-02-423
15 Main burner sparker 70-01-283
16 SearPLUS™ burner sparker 70-01-112
17 Main burner & heat tent support 70-01-915
18 SearPLUS™ burner & heat tent support 70-01-916
19 Firebox assembly-With heat shield 70-01-917
20 Main valves and manifold assembly 70-02-271
21 Corrugate hose 70-01-645
22 Side valve 70-02-106
23 Regulator and hose assembly 70-02-414
24 Main Control panel assembly 70-02-039
25 Left side table 70-02-040
26 Left side table facing panel 70-02-041
27 Control knob bezel for main burner 70-02-042
28 Control knob for main burner 70-02-043
29 Smoker box assembly 70-02-441
30 Smoker box lid with hardware 70-01-929
31 Smoker box body with hardware 70-01-930
32 Smoker box front support with hardware 70-01-932
33 Grease pan 70-01-933
34 Grease cup 70-01-187
35 Upper Cart Brace 70-02-044
36 Door upper axis 70-09-114
37 Cylinder exclusion 70-01-935
38 Cart Rear Panel 70-02-045
39 Cart Left Side Panel Assembly 70-02-046
40 Cart Right Side Panel Assembly 70-02-047
41 Left door assembly 70-02-048
42 Right door assembly 70-02-049
43 Match holder with chain 70-01-204
