Hardware Contents
Preparation
Before beginning assembly of product, make sure all parts are present. Compare parts with package
contents list on previous page and hardware contents above. If any part is missing or damaged, do not
attempt to assemble the product. Contact customer service for replacement parts.
Estimated Assembly Time: 50 minutes with 2 people.
Tools Required for Assembly and Leak Testing (not included): Phillips screwdriver, Spray bottle
CAUTION
THIS UNIT IS HEAVY. Two people required for safe assembly.
Two people required for safe assembly. Some parts may contain sharp edges.
Wear protective gloves if necessary. Read and follow all safety statements,
warnings, assembly instructions and use and care instructions before attempting
to assemble and use.
AA
BB CC
M6x16
Screw
43X 2X8X
2X 1X
M6 Wing
Nut
DD
GGEE
M10
Wrench
2X
FF
2X
M4x12
Screw
M6 Plain
Washer
Door Upper
Hinge Pin
M6 Spring
Washer
HH
2X
M4x8
Screw
To Next Page
