PACKAGE CONTENTS
A
D
C
E
F
G
B
J
I
H
K
L
R
S
Q
O
P
N
M
T
U
V
W
PART DESCRIPTION QUANTITY
A Side Shelf 2
B Lid and Firebox Assembly 1
C Lid Handle Assembly 1
D Smoke Stack Assembly 1
E Charcoal Access Door-Left 1
F Crank Handle 2
G Damper Handle-Right 1
H Damper 2
I Side Shelf Support-Right 2
Rear/Left Front
J Ash Tray 1
K Ash Tray Handle 1
L Cart Brace 2
M Right Leg Assembly 1
N Caster 2
PART DESCRIPTION QUANTITY
O Storage Basket 1
P Axle 1
Q Wheel 2
R Left Leg Assembly 1
S Charcoal Access Door-Right 1
T Grate 4
U
Warming Rack
1
V Damper Handle-Left 1
W Side Shelf Support-Left 2
Rear/Right Front
X Charcoal Tray 2
Y Divider Panel 1
Z Temperature Gauge 1
A1 Temperature Gauge Nut Bezel 1
Z
A1
X
Y
