Dyna-Glo DGSS675CB-D - Step 3-4: Rear Legs, Bottom Shelf & Wheels

7
ASSEMBLY INSTRUCTIONS
3. Before attaching the rear legs, insert the bottom
shelf (O) posts into the holes located on all four
legs. With the bottom shelf (O) securely in place,
attach the left rear leg (M) and right rear leg (S)
using four M6 x 12 bolts (AA), four M6 nuts (BB)
and four M6 flat washers (CC), per leg.
4. Insert the wheel axle (R) through the holes in the
right front and right rear legs (S) and attach the
left and right wheel (P) using one M12 nut (DD)
per side.
P
S
S
O
DD
3
4
Hardware Used
DD
M12 Nut
x 2
AA
R
Hardware Used
AA
M6 x 12mm
Bolt
x 8
BB
M6 Nut
x 8
CC
M6 Flat Washer
x 8
M
CC
BB
