5
MOUNTING THE BRACKET
Refer to Figures 4a and 4b.
1. Locate a wood stud in the wood ceiling joist. If you cannot locate a wood stud, you
have to install a wood piece on the ceiling as this heater must be securely fastened.
2. Remove the mounting bracket from the heating unit by loosening bracket screws with
a wrench and slipping the handle off over the screw heads.
3. Place a washer on screws before inserting through the holes in the mounting bracket
and screw them securely into a ceiling joist.
NOTE: If you want to swivel the heater either to the right or left adding a washer to
both sides of the bracket is recommended. A longer lag bolt may be required to properly
secure the unit. See Figure 4a.
4. LOCATING HEATER
5. INSTALLATION
Figure 3
Wood Ceiling
Wood Ceiling
To Next Page
