ASSEMBLY INSTRUCTIONS
17. Insert the grease pan (B1) into position by
sliding it in the grill body from the rear as
shown on below gure, along the rails located
just below the underside of grill body.
NOTE: Pay attention and do not slide the
grease pan from opposite position. Insert
grease cup (A1) into position by sliding it onto
the rail on the bottom side of grease pan as
shown.
17
B1
A1
