NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
15
DRAWING
NUMBER
1
2
3
3-1
4
5
6
7
7-1
8
9
10
11
12
13
13-1
14
15
16
16-1
17
17-1
18
19
19-1
20
21
21-1
22
23
24
24-1
25
26
TOP GRILLE
CARRYING HANDLE
TOP PLATE(WHITE)
TOP PLATE (BLACK)
BURNER ASS'Y
WICK COVER
REAR GRILLE
CABINET BASE(WHITE)
CABINET BASE ( BLACK )
WIND COVER
WICK ADJUSTER ASS'Y
(COMPLETE)
WICK
WICK ADJUSTER GASKET
SAFETY SHUT OFF DEVICE
DRIP TRAY ASS'Y(WH
ITE)
DRIP TRAY ASS'Y(BL
ACK)
FUEL CAP GASKET
FUEL CAP ASS'Y
WICK ADJUSTER KNOB(WHITE)
WICK ADJUSTER KNOB(BLACK)
BATTERY CASE ASS'Y(WHITE)
BATTERY CASE ASS'Y(BLACK)
FRONT GRILLE
CABINET(WHITE)
CABINET(BLACK)
MICA WINDOW
DOOR(WHITE)
DOOR(BLACK)
FUEL GAUGE
FUEL GAUGE GASKET
TANK ASS'Y(WHITE)
TANK ASS'Y(BLACK)
IGNITER ASS'Y
WICK SLEEVE
PS-CV01
WS-CV02R
WS-CV03
WS-CV03B
2112-0067-00
WS-CV25
PS-CV060
2118-0053-01
2118-0053-02
WS-CV17
2113-0047-00
2114-0053-00
PS-CV19R
See 9
PS-CV32R1
PS-CV32R1B
WS-CV30
WS-CV29
WS-CV14
WS-CV14B
2118-0031-00
2118-0031-01
PS-CV061
2118-0054-01
2118-0054-02
WS-CV09
WS-CV34
WS-CV34B
WS-CV21
WS-CV22
2111-0088-01
2111-0088-02
2117-0023-00
PS-CV35
PARTS LIST EXPLODED PARTS DRAWING
DESCRIPTION
PART
NUMBER
NOTE :
SPECIFY MODEL NUMBER AND
PART NUMBER WHEN ORDERING PARTS.
SPECIFICATIONS
Model No.
Type of Heater
Heat Output
Fuel Tank
Tank Capacity
Continuous Combustion Time
Max. Fuel Consumption
Ignition Method
Dimensions
Wick Height
Replacement Wick Part Number
WK95C8 / WK95C8B / WK95C8C / WK24WH / WK24BK
Convection
Max. 23,800 BTU/hr
Integral
1.9 U.S. gallons
Approx. 9-12 hr
0.180 U.S. gallons/hr.
Battery-C Cell x2, Igniter Type "B"
27 inches
17.5 inches
17.5 inches
25/64 IN. (10mm)
2114-0053-00
Height
Width
Depth
2
1
3, 3-1
4
6
19, 19-1
21, 21-1
7, 7-1
8
9
10
5
20
16, 16-1
12
11
15
14
13, 13-1
18
17, 17-1
26
24, 24-1
22
23
25
