Install IO Board according to the following procedures and Figures 4-23.
1.
Place IO Board in correct position.
2.
Securing IO Board with three M2.0x3.0x4.5 black Phillips head screw.
3.
Connect following cable to the connector on System Board:
-IO Board cable from JDB1
4.
Stick tape on the IO Board.
