dynabook C50-J-12A - 4.13 CCD Module; Removing the CCD Module

NOTE: Touch SKU will provide the FRU parts as LCD Module Assembly. This chapter
only for Non-Touch SKU.
4.13 CCD Module
Removing the CCD Module
Remove the CCD Module according to the following procedures and Figure 4-33
1. Lift the CCD Module from the LCD module cover.
2. Disconnect LCD cable from CCD Module connector.
Figure 4-33Removing the CCD Module
