1.4 Installation (For Rugged Camera)
For Rugged Camera, we suggest you to install the Camera as the following
steps to make sure the Camera is well waterproof.
Step 1:
Put the Rubber Washers in both
sides of the holes on the Bottom
Plate of the Camera.
Step 2:
Aim the installing hole to the target
installing position and fasten the
screws to attach the Camera to the
ceiling.
Step 3:
Refer to 1.5 Connectors and 2. Camera Cabling to connect the cable and
adjust the lens.
Step 4:
Aim the arch parts on both Dome
Cover and Bottom Plate to attach
two parts firmly together. And then
fasten the security screws on the
Dome Cover to finish installing the
Camera.
