Dynacord AXM 12A User Manual

Technical data
Description Powered monitor speaker for multifunctional
applications
Maximum amplifier output
capability, IHF-A
520 W
Low amplifier power 360 W IHF-A, 260 W RMS
Mid-high amplifier power 160 W IHF-A, 75 W RMS
Maximum SPL (1 meter) 128 dB (calc.)
Frequency range (-10 dB) 50–20000 Hz
Coverage angle nominal 90° horizontal x 90° vertical
Crossover frequency 1.6 kHz
Transducer DCX 12300, 12-inch/1.75-inch 2-way coaxial transducer
with lightweight neodymium compression driver
Audio sockets
• Inputs 2 x Mono XLR/Jack socket (MIC/LINE), switchable
phantom power (+15 V)
1 x Stereo RCA (AUX IN)
• Outputs 1 x XLR THRU (parallel to MIC/LINE 1)
1 x XLR MIX OUT
Equalization
• Low shelving filter ±10 dB / 60 Hz
• Mid peak filter ±10 dB / 70–12000 Hz
• High shelving filter ±10 dB / 12 kHz
Filter
• Low-cut filter f = 50–200 Hz, 12 dB/oct.
• Feedback filter 70–10000 Hz, Notch, -10 dB
Master delay 0–100 m
Settings 6 factory presets, 5 user settings
Display Blue backlit LC-display, dimmable
AC power input 100–240 V AC, 50–60 Hz
AC power consumption 0.8–0.5 A
Cooling Passive
Safety class I
Operating temperature 0 °C to 40 °C
Product dimensions (Width x Height
x Depth)
414 x 339 x 484 mm
10
AXM 12A Technical data | en 19
Bosch Sicherheitssysteme GmbH User manual 18-Mar-14 | 02 | F01U290507

Dynacord AXM 12A Specifications

General

XLR out	2
AC (power) in	Yes
Audio (L/R) in	1
Frequency range	50 - 20000 Hz
Product color	Black
Rack mounting	No
Volume control	Rotary
Housing material	Plywood
RMS rated power	520 W
Woofer diameter (imperial)	12 \
Tweeter diameter (imperial)	1.75 \
Display type	LCD
Operating temperature (T-T)	0 - 40 °C
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz

Weight and Dimensions

Depth	484 mm
Width	414 mm
Height	339 mm
Weight	14900 g
Package weight	18400 g
