MIXER AMPLIFIER Owner’s manual
MV 503
MV 506
MV 512
Description:
• 1 balanced 6.3mm input jack, line / micro switchable sensitivity
•
2 balanced XLR microphone inputs, with excludable 24V dc phantom supply
• 1 unbalanced 6.3mm input jack, line / micro switchable sensitivity
• 1 stereo RCA input, line sensitivity
• 1 “PRE OUT” output
• 1 “TAPE OUT” output
•
1 “MAIN IN” input
• Input 1 priority on the other inputs with vocal activation
• Input 1, 2, 3 priority on the other inputs, activation with contact
•
Outputs for speakers with constant impedance (4ohm) and constant voltage (25-70-100V)
• Treble, bass and volume controls
• Protection against short-circuiting between output terminals
• Vu-meter with LEDs
• Output for “Music on hold” function
•
115/230 V mains supply, switchable
• 24V battery power
9
