ASSEMBLY
Your new vehicle requires adult assembly. Please set aside around 25
minutes for assembly. Please identify all parts before assembly and save all
packaging material until assembly is complete to ensure that no parts are
discarded.
Tools Required:
Phillips Screwdriver (not included)
Standard slip joint pliers (not
included)
WARNING:
Children can be harmed by small parts, sharp edges and
sharp
points in the vehicle’s unassembled state, or by electrical items. In the
unassembled
state, this package contains small parts. Adult assembly is
required; children should
not handle parts, or help in assembly of the vehicle.
1. Steering Column Assembly
● Turn the vehicle body on its side.
● Insert the straight end of steering column through the hole under vehicle
body until it sticks out of the hole on the top of the car body. <see diagram
1-1>
● Insert the bent end of steering column through the hole on the steering
bracket (which connects with the front wheel axle).
● Fit a Ø10 washer onto the bent end of the steering column and insert split
pin into the hole in the steering column, use standard slip joint pliers to
open and
split the pin ends (to assure the Ø10 washer will not fall out). <see
diagram 1-2>
9
