Dynamic RHINO2 DS160 User Manual

GBK51948 RHINO2
Installation Manual Issue 5
6.5.7 Battery Management
6.5.7.1 Overvoltage Rollback
Parameter Possible Values Default HHP Lite Std Adv
Overvoltage Warning 24 - 30.2 V 30.2 V
✓
Overvoltage Rollback 30.2 – 36.2 V 34.2 V
✓
Set Overvoltage Warning to the voltage at which the controller will begin slowing the
scooter to protect the batteries from an over-voltage condition.
Set Overvoltage Rollback to the voltage at which the controller will stop driving the scooter
to protect the batteries from an over-voltage condition.
6.5.7.2 Undervoltage Rollback
Parameter Possible Values Default HHP Lite Std Adv
Undervoltage Rollback Start 18 - 32.2 V 21 V
✓
Undervoltage Rollback End 17 - 21 V 18 V
✓
If the battery voltage falls below Undervoltage Rollback Start , the RHINO2 reduces the
maximum throttle input value, so the user cannot ask for full speed anymore. This
l
protects the battery,
l
gives the scooter a longer range before the battery is completely empty, and
l
gives the user a physical warning that the battery is almost empty before the battery
is damaged.
The scooter will drive slower but should still be able to climb small obstacles such as curbs.
If the battery voltage falls below Undervoltage Rollback End , the scooter stops driving
because the throttle is reduced to zero.
Figure 58: Undervoltage rollback (start and end)
Page 108 - Programming
