Dynamic RHINO2 DS160 - Page 68

GBK51948 RHINO2
Installation Manual Issue 5
Parameter Possible Values Default HHP Lite Std Adv
Testing Latching
Throttle Fault Non
Latching
No / Yes No
✓
Speed Limit Pot No / Yes No
✓
Slam Brake Enable No / Yes No
✓
Slam Brake Threshold 6 - 94% 13%
✓
Enable SRW Open
Circuit Testing
No / Yes No
✓ ✓ ✓
Drive Performance (6.5.3 Drive Performance)
Maximum Forward
Speed
20 - 100 %
See 6.4 Parameter
Variations
✓ ✓ ✓ ✓
Forward Acceleration 0 - 100 %
See 6.4 Parameter
Variations
✓ ✓ ✓ ✓
Forward Deceleration 0 - 100 %
See 6.4 Parameter
Variations
✓ ✓ ✓ ✓
Maximum Reverse
Speed
20 - 100 %
See 6.4 Parameter
Variations
✓ ✓ ✓ ✓
Reverse Acceleration 0 - 100 %
See 6.4 Parameter
Variations
✓ ✓ ✓ ✓
Reverse Deceleration 0 - 100 %
50 % (Profile1)50 %
(Profile 2)
✓ ✓ ✓ ✓
Lowest (Minimum)
Forward Speed
0 - 100 %
20 % (Profile1)20 %
(Profile 2)
✓ ✓ ✓ ✓
Lowest (Minimum)
Reverse Speed
0 - 60 %
20 % (Profile1)20 %
(Profile 2)
✓ ✓ ✓ ✓
Soft Start Period 0 - 2550ms 800ms ✓
✓ ✓
Soft Finish 0 - 100 % 35 % ✓
✓ ✓
Emergency
Deceleration
0 - 100 % 80 %
✓
Slam Braking 0 - 100 % 50 %
✓
Push Speed 5 - 70 % 15 %
✓
Roll-away Speed 5 - 70 % 15 %
✓
SRW Forward Speed
Limit
0 - 100 % 50 %
✓ ✓
SRW Forward Speed
Scale
0 - 100 % 50 %
✓ ✓
SRW Reverse Speed
Limit
0 - 100 % 50 %
✓ ✓
SRW Reverse Speed
Scale
0 - 100 % 50 %
✓ ✓
SRW Scaling Resistor
(Ohm)
400 - 25500Ω 3200Ω
✓ ✓
SW Current Limit Decel
6 – 94% 75% (DS90)
✓
Page 66 - Programming
