Installation, Operation and Service Manual LKAT

+24V

046404 E

Optional PE PCB – Current Loop Output

• Output Bias (coarse) : SW4

• Output Type : SW5

• Output Gain (coarse) : SW1 and SW2

• Output Bias (fine) : Trimpot

• Output Gain (fine) : Trimpot

Optional PE PCB – Trip 2 & 3 Setpoints

• Trip 2 Protection Polarity : SW3

• Trip 2 Setpoint : R33 (medium) and R46 (fine)

• Trip 3 Protection Polarity : SW3

• Trip 3 Setpoint : R34 (medium) and R47 (fine)

Optional RMS Display PCB – Display

• Decimal Point position

• DPM Mode

• RMS Signal Conditioning Options : SW1F, G, & H (SW1-6, 7, & 8)

• Input Scale Factor : SW1E (SW1-5)

• Input Attenuation : SW1A, B, C, & D (SW1-1, 2, 3, & 4)

• DPM Gain (fine) : R12

NOTE

The Optional PE and/or RMS Display pc board assemblies may be added, configured

and calibrated in the field. In this case, the Main pc board assembly output signal is used

as the reference output signal with the LKAT

System measuring normal bus current.
