Long-Term Care Bed • D100 (Reorder No. 12001) 11
ASSEMBLY INSTRUCTIONS (Continued)
2.8 INSTALLING THE BATTERY
BACKUP
1. Unplug the bed when installing the backup battery.
2. Afx the battery backup with nuts and bolts to the
side of the control box, on the same holding plate.
3. Open the control box locking lid by pressing in the
sides and lift it up, to expose the connection parts.
4. Connect the back up battery cord to the control
box. The connection port is indicated with a bat-
tery symbol above.
5. Close the locking lid, there should be a audible
click, switch the power supply back on.
