TECHNICAL SPECIFICATIONS
Due to continuous Development, these specifications are
subject to change without notice.
Inputlevelfor85dBSPL@1m,@0dBsetting,unbalanced: 80mVrms
Maxinputlevel(@setting):  4,8Vrms(-10dB)
   1,5Vrms(0dB)
   1Vrms(+4dB)
Power consumption: Standby: 0.3 W
Idle: 5.8 W
   Max:94W
Amplifier power: Tweeter: 50 W
Woofer: 50 W
MaxSPL1m,normalroom,shorttermIECsignal: 117dBpeak
FrequencyResponse:(+/-3dB):  46Hz–21kHz
Resonance Frequency: 39 Hz
InternalCabinetVolume:  13.9litres
BassPrinciple:  Bassreflex
Weight: 7.2 kg
Dimensions (W x H x L): 230 x 335 x 348 mm
Crossover: 2 way
Crossover Frequencies: 1500 Hz
CrossoverSlope:  12dB/oct
Connection: XLR balanced and
RCA unbalanced
Recommended Placing: Desktop
Remarks
Tweeter: D-281 - 28 mm soft dome, rear chamber, magnetic fluid
4mm aluminium front
Pure aluminium wire voice coil
Woofer: 18cm moulded aluminium frame
  OnepiecethermoformedMSPcone
75 mm voice coil with pure aluminium wire on kapton former.
Cabinet: Designed to be placed on a desk.
Angular cabinet design to reduce internal standing sound waves.
  18mmMDF
Crossover: Active, DSP based
Amplifier: Input sensitivity selector
  HF,MFandLFtrimselector
High pass frequency selector
Auto standby/On selector
Remote volume control (cabled)
High efficiency digital power amplifiers.
Switch mode power supply with wide range input
