34
For a typical karaoke system connect the high level
output of an audio source for the playback music
(CD player, computer, portable player etc.) using an
RCA cable with one of the inputs being “AUDIO
INPUT”. Connect a dynamic microphone to the
microphone input socket “MIC IN” on the front of
the device. If the karaoke mix is to be recorded,
connect the recording output “REC OUT” to the high
level input of a recording device (tape, CD recorder
etc.). The loudspeakers must be connected, each
with a loudspeaker cable, to the two loudspeaker
outputs “R” (right) and “L” (left) in the connection
area “TO SPEAKER”.
TYPICAL KARAOKE SYSTEM
