39
Operation
Switch on and off
Change the volume
Adjust audio sources
with a higher signal
level to the amplifier
Button(s)
POWER
(1)
VOLUME
(8)
SIGNAL IN
(9)
Description
The amplifier is switched on and off using this button at the front
panel. When switched off the device is internally separated from the
AC power. The LED next to the mains switch lights up when the
device is switched on. As a precaution, after switching on, the volu-
me setting (8) should be reduced.
Turn the knob “VOLUME” clockwise to turn up the volume and
counter-clockwise to turn it down. The volume setting does not
influence the signal at the output “REC OUT” (10).
This switch should be left in the “HIGH” position for common
high level sources (CD players, tuners etc.). It must only be set to
“LOW” if the amplifier is overdriven by the input signal (very loud,
distorted, clipping or effective area of control is in the lower range).
OPERATING THE APPLIANCE
