Dyness Junior Box - Specifications

©Dyness reserves the copyright of this document
9
 If the MPPT fails and needs to be replaced, first plug the MC4 wiring harness, then press the MPPT
buckle and pull out the MPPT module.
BASIC
Battery Type
LiFePO4
System Energy
1.6KWh
Dimensions
420mm*283.5mm*245mm
Weight
18KG
Protection Level
IP55
Cycle Life
≥8000 Cycles
Warranty
10 Years
Charging Temp. Range
0 °C to 55 °C
Discharging Temp. Range
-20 °C to 55 °C
APP
Yes
Communication
RS485
Max.PV Input Power （ W ）
1200W
Max. Input Voltage （ V ）
65V
MPPT Range(V)
18-60V
Click here to pull out the MPPT
module
Pull out the MPPT
module
Specifications
