Dyness Junior Box - Button Controls; Getting Started

©Dyness reserves the copyright of this document
2
➊ BMS
➎ MC4 ports for PV2-
➋ MC4 ports for PV1+
➏ MC4 ports for PV2+
➌ Power Button
➐ MC4 ports for DC-(To Micro INVT)
➍ MC4 ports for PV1-
➑ MC4 ports for DC+(To Micro INVT)
Button Controls
Button
Action
Function
Press for 3 seconds
Turn Junior Box on
Press for 3 seconds
Turn Junior Box off
Install Your Junior Box
Option A: Position your Junior Box on a hard, level floor.
Getting Started
➊
➋
➌
➍
➎
➏
➐
➑
