Group 3 Function Sec. As Set
PI.FSV Primary Input Full Scale Value 6.1.4
PI.LSV Primary Input Low Scale Value 6.1.5
PI.DP Primary Input Decimal Point Position 6.1.6
A1.LNK Alarm 1 Input Channel Link 6.2.1
A1.TYP Alarm 1 Type 6.2.2
A2.LNK Alarm 2 Input Channel Link 6.2.1
A2.TYP Alarm 2 Type 6.2.2
A3.LNK Alarm 3 Input Channel Link 6.2.1
A3.TYP Alarm 3 Type 6.2.2
CO.LO Control Output Range Low 6.4.5
CO.HI Control Output Range High 6.4.5
CO.DP Control Output Decimal Point Position 6.4.5
RO.LO Retransmission Range Low 6.3.2
RO.HI Retransmission Range High 6.3.3
SP.LO Set Point Limit Low 5.4.3
SP.HI Set Point Limit High 5.4.3
MA.STP Manual / Auto Start-Up 7.3.6
SC.ADR Serial Communication Interface Address 8.3.1
SC.BUS Protocol Type 8.3.2
SC.FRM Communication Type 8.3.3
SC.BDR Communication Baud Rate 8.3.4
DEFLT Loading Default Data 5.2.3
Group 4 Function Sec. As Set
SHUNT Shunt Calibration 5.3.1
SHNT.% Shunt Value 5.3.1
PI.IFS Primary Input Fail Safe 6.1.7
RI.IFS Remote Set Point Input Fail Safe 5.4.2
A1.HYS Alarm 1 Hysteresis 6.2.4
A1.RES Alarm 1 Reset Mode 6.2.5
A1.FSM Alarm 1 Failsafe Mode 6.2.6
A2.HYS Alarm 2 Hysteresis 6.2.4
A2.RES Alarm 2 Reset Mode 6.2.5
A2.FSM Alarm 2 Failsafe Mode 6.2.6
A3.HYS Alarm 3 Hysteresis 6.2.4
A3.RES Alarm 3 Reset Mode 6.2.5
A3.FSM Alarm 3 Failsafe Mode 6.2.6
LI.TYP Logic Input Configuration 5.3.2
LI.ST Logic Input Status 5.3.3
PEAK Peak Detection 5.3.5
MA.TRF Manual / Auto Transfer 7.3.7
SP.RMP Set Point Ramp 7.3.7
CO.MAX Control Output Limiter 6.4.3
CO.MMI Control Output Manual Mode Indication 6.4.4
CO.D/R Direct/Reverse Selection for Control Output 6.4.2
