ATC770 Microprocessor-Based Pressure/Process Controller 63
Group 4 Function Sec. As Set
LINE.F Line Frequency 5.3.6
DEFLT Loading Default Data 5.2.3
Group 5 Function Sec. As Set
PI.TYP Primary Input Selection 6.1.1
RI.TYP Remote Set Point Input Selection 5.4.1
CO.TYP Control Output Selection 6.4.1
RO.TYP Retransmission Output Selection 6.3.1
DEFLT Loading Default Data 5.2.3
Group 9 Function Sec. As Set
AT.TO Process Time Delay 7.3.8
AT.TAU Process Time Constant 7.3.8
AT.KP Process Gain 7.3.8
AT.TI Start Time of Start Function 7.3.8
AT.T2 Stop Time of Start Function 7.3.8
Enter your individual settings in the As Set column.
11.1 GROUP 1 PARAMETERS
SET POINT - Group 1
Available: Always
Upper display: Set point value
Lower display: SP
Range: From SP.LO to SP. HI.
ALARMS MASK RESET - Group 1
Available: Only if one or more alarms are configured with mask at start-up
Upper display: OFF
Lower display: AL.MSK
Range: Use the ▲ and ▼ keys to switch the upper display from OFF to RESET, then press
the FUNC key to restore the alarm mask.
Default value: not applicable
SECURITY - Group 1
Available: Only if CODE.A or CODE.B or CODE.C are On.
Upper display: A b C or A b C. or A b. C or A. B. C. One or more digits followed by a decimal
point means that the access to modification of the parameters of the related security
level is inhibited.
Lower display: SECUR
Range: Use ▲ and ▼ keys to input the security code; if the selected code matches the
programmed code the parameters of the related security level are unlocked. The
