ATC770 Microprocessor-Based Pressure/Process Controller 61
Part 4: Testing and measurement techniques -
Section 8: Power frequency magnetic field immunity test
IEC 1000-4-4: Electromagnetic compatibility (EMC) -
Part 4: Testing and measurement techniques -
Section 4: Electrical fast transient/burst immunity test
ENV50141: Electromagnetic compatibility - Basic immunity standard - Conducted
disturbances induced by radio-frequency fields - Immunity test
11. ATC770 PARAMETER GROUP MENUS
Group I Function Sec. As Set
SP Set Point 7.2
AL.MSK Alarms Mask Reset 6.2.8
SECUR Security 6.5
A/M Auto / Manual 5.3.4
AL1 Alarm 1 Threshold 6.2.7
AL2 Alarm 2 Threshold 6.2.7
AL3 Alarm 3 Threshold 6.2.7
DEFLT Loading Default Data 5.2.3
GROUP Group Access Number N/A
Group 2 Function Sec. As Set
ZERO.C Zero Calibration 7.1.1
SPAN.C Span Calibration 7.1.1
SMART Self Tuning 7.2.2
RLTM Time of Smart Function 7.3.3
AT.STP Step for Smart Function 7.3.3
PB Proportional Band 7.3.3
TI Integral Time 7.3.3
TD Derivative Time 7.3.3
AT.IP Automatic Selection of the Integral Pre Load Value 7.3.3
IP Integral Pre Load 7.3.3
AT.TYP Type of Control 7.3.1
AT.AFL Automatic Selection of the Filter Time Constant 7.3.3
AT.FL Filter for Display and Controller 5.3.7
ASB Automatic Stand-By 7.3.5
ASB.PL Automatic Stand-By Pressure Low Limit 7.3.5
ASB.RT Automatic Stand-By Recovery Time 7.3.5
LR.SP Local / Remote Set Point Selection 5.4.4
A1.FL Alarm 1 Filter 6.2.3
A2.FL Alarm 2 Filter 6.2.3
A3.FL Alarm 3 Filter 6.2.3
RO.FL Retransmission Output Filter 6.3.4
DEFLT Loading Default Data 5.2.3
