Dyson DC22 - Page 18

Service manual
Fitting notes
17 Release the cable rewind from the
catch (catches on DDM products)
on the side of the product.
18 Release the cable rewind fly leads
from the retaining channels.
Remove the cable rewind.
15
Models with finger
tip controls only
Models without
finger tip controls
19 Detach the live wire from the
switch.
