Service manual
Fitting notes
22
34 Locate the top of the cable collar
into the rear of the cable rewind
housing. Firmly snap the bottom
of the cable collar into place.
35 Place the wheel assembly onto
the side of the product. Align the
wheel cap lugs with the guide
recesses on the product. Push into
place.
36 Lower the parking yoke onto the
chassis. Fit the screw.
