Service manual
Fitting notes
DDM models only
AC models only
50 Carefully detach the ribbon cable
from the switch.*
48 Slide the switch out of the housing.*
AC models with finger tip
controls only
49 Carefully release the connectors
from the switch terminals using a
thin, flat bladed screwdriver.*
* Only necessary if replacing the switch.
27
