Service manual
Fitting notes
50
DDM models only
AC models only
DDM models only
109 Lower the AC motor bucket into
the chassis. The windows in the
bucket should align with those
in the chassis. Fit the five screws.
110 Locate the wires from the DDM
assembly through the slot
in the chassis. Fit the five screws.
111 Ensure the grommet is pulled
through and seated correctly
against the outside of the
chassis.
