cyclone and lift the cyclone out.
To detach the clear bin from the appliance, pull back on the red catch located at the base, slide the clear bin down, and carefully remove forwards from the main body.
Clean the clear bin with a damp cloth only.
Do not use detergents, polishes or air fresheners to clean the clear bin.
Do not put the clear bin in a dishwasher.
Ensure the clear bin is completely dry before replacing.
To replace the clear bin, align the tabs on the clear bin with the grooves on the main body and slide upwards into place until the latch clicks.
Slide the cyclone into the grooves of the main body and push downwards until it is in its normal position and manually close the base of the bin – the base will click when it
is securely in place.
Washable parts
Your appliance has washable parts, which require regular cleaning. Follow the instructions below.
Washing the filters
Your appliance has two washable filters; wash the filters at least once a month according to the following instructions to maintain performance. More frequent washing may
be required where the user: vacuums fine dust, operates mainly in ‘Powerful suction’ mode or uses the machine intensively.
Washing filter A
Ensure the appliance is disconnected from the charger before removing the filter. Be careful not to pull the ‘ON’ trigger.
Check and wash the filter regularly according to instructions to maintain performance.
The filter may require more frequent washing if vacuuming fine dust or if used mainly in ‘Powerful suction mode.
To remove the filter, lift it out of the top of the appliance.
Wash the filter with cold water only.
Run water over the outside of the filter until the water runs clear.
Squeeze and twist with both hands to make sure the excess water is removed.
Leave the filter to dry completely for a minimum of 24 hours.
Do not put the filter in a dishwasher, washing machine, tumble dryer, oven, microwave or near a naked flame.
To refit, place the dry filter back into the top of the appliance. Make sure it is seated properly.
Washing filter B
To remove the filter, twist anti-clockwise to the open position and pull away from the appliance.
Wash the inside of the filter under cold running water, rotating the filter to ensure all pleats are covered.
Gently tap the filter against the side of the sink several times to remove any debris.
Repeat this process 4-5 times until the filter is clean.
Place the filter upright, with the Max button facing upwards, and leave to dry completely for a minimum of 24 hours.
To refit, return the filter to the open position and twist clockwise until it clicks into place.
Blockages – automatic cut-out
This appliance is fitted with an automatic cut-out.
If any part becomes blocked the appliance may automatically cut out.
This will happen after the motor pulses a number of times (i.e switches on and off in quick succession).
Leave to cool down before looking for blockages.
Ensure the appliance is disconnected from the charger before looking for blockages.
Failure to do so could result in personal injury.
Clear any blockage before restarting.
Refit all parts securely before using.
Clearing blockages is not covered by your Dyson guarantee.
Looking for blockages
The motor will pulse when there is a blockage. Please follow the instructions below to locate the blockage:
Ensure the appliance is disconnected from the charger before looking for blockages.
Be careful not to pull the ‘ON’ trigger.
Do not operate while checking for blockages. Doing so could result in personal injury.
Beware of sharp objects when checking for blockages.
To check for blockages in the main body of the appliance, remove the clear bin and cyclone as per the instructions in the cleaning the clear bin section and remove the
blockage. Please consult the ‘Stubborn blockages’ section of the illustrations for further guidance.
If you cannot clear an obstruction you may need to remove the brush bar. Use a coin to unlock the fastener marked with a padlock. Remove the obstruction. Replace the
brush bar and secure it by tightening the fastener. Ensure it is fixed firmly before operating the appliance.
This product has carbon fiber brushes. Take care if coming into contact with them, as they may cause minor skin irritation. Wash your hands after handling the brushes.
Refit all parts securely before using.
Clearing blockages is not covered by your Dyson guarantee.
Charging and storing
This appliance will switch ‘OFF’ if the battery temperature is below 3°C (37.4°F).
This is designed to protect the motor and battery. Do not charge the appliance and then move it to an area with a temperature below 3˚C (37.4°F) for storage purposes.
To help prolong battery life, avoid recharging immediately after a full discharge.
Allow cooling for a few minutes.
Avoid using the appliance with the battery flush to a surface. This will help it run cooler and prolong battery run time and life.
Battery safety instructions
If the battery needs replacing please contact the Dyson Helpline.
Use only Dyson chargers for charging this Dyson appliance.
The battery is a sealed unit and under normal circumstances poses no safety concerns. In the unlikely event that liquid leaks from the battery do not touch the liquid and
observe the following precautions:
– Skin contact – can cause irritation. Wash with soap and water.
– Inhalation – can cause respiratory irritation. Expose to fresh air and seek medical advice.
– Eye contact – can cause irritation. Immediately flush eyes thoroughly with water for at least 15 minutes. Seek medical attention.
– Disposal – wear gloves to handle the battery and dispose of it immediately, following local ordinances or regulations.
