28 E-flite Apprentice Assembly Manual
12. Check the movement of the aileron using the
transmitter. When the aileron/elevator stick (Mode
2 transmitter) or the aileron/throttle stick (Mode 1
transmitter) is moved left, the left aileron will move up
and the right aileron will move down.
Reversing Direction of Flight Controls
If you find any control surface moving in the opposite direction of
what it should (example shown below), use the Servo Reversing
feature of the DX5e to fix the problem. Reversing switches for all
of the control functions are located on the front of the transmitter
below the power switch. Locate the appropriate switch, slide it
to the new position, and check to see if the surface in question is
now moving in the right direction.
