Wing Joining
Required Parts
Wing halves (L and R)
(2) dihedral joiners
(2) leading edge dowels
(2) 6-32 x 1” socket head bolts
(2) #6 steel washers
Required Tools and Adhesives
Low-tack tape
12-minute epoxy
Clear tape
7/64” balldriver
Mixing cups
Mixing sticks
Rubbing alcohol
Paper towels
Ο Ο 1. Install the leading edge dowels in the wing panels with 12-minute
epoxy. Use paper towels and rubbing alcohol to clean any epoxy that
squeezes out onto the wing.
Ο Ο 2.. Upon installation, approximately 5/16” to 3/8” of the dowel should
protrude from the leading edge of the wing.
Ο Ο 3. The rear side of the dowel is accessible through the wing root rib and a
small amount of epoxy can be added here to secure its installation.
