CLASS 3400 METER
62-0391-03 10
3.0 METER TECHNICAL SPECIFICATIONS
(CONTINUED)
RS-485 Serial
Communications
Cable: UL-listed stranded conductors,
22-26 AWG.
Input/Output Voltage: Ground-isolated +/-5.4VDC
Cable Connector: Screw terminal termination
Circuit Input Isolation: 5.3kVAC
Max Cable Distance: 4000 feet
Max Network Nodes: 64 cabling nodes (including
master)
Baud Rate: 9600
Ethernet
Communications
Cable
Cable: UL-Listed CAT-5e cable, 8-
conductor, stranded 24 AWG
Cable Connector: RJ-45 termination
protocol: 10/100 base T
Cable Distance: 450 feet
Load Control
Contacts:
Contact Closure: Set by user
Contact Rating: 28Vdc@10A; 240VAC@10A
Mating Connector: Weidmuller PN 1526510000
Isolation Voltage: 1.5K VAC for 1 minute
Recommended
In-line Fuse
Manufacturer: Littlefuse
Mfg. Part No: KLDR.100
Rating: 100mA, time-delay, 600VAC
cartridge fuse
Battery Cell Description: Non-rechargeable cell used for
memory retention
Manufacturer: Panasonic
Mfg Part No: CR2032
Working Voltage: 3 Vdc
Current Capacity: 225 mAHr
Electrolyte: Manganese Dioxide Lithium
