3.0 METER TECHNICAL SPECIFICATIONS
Ordering Information: Define brand, class, input voltage, current sensor rating,
enclosure, protocols/options, expanded feature package, and sensor type in the format
A-BB-CCC-DDDD-E-FF-G-HHH, where:
A = Brand: E for E-Mon
BB = designates Class: 3200 (32), 3400 (34), or 5000 (50) meter
CCC = input voltage: (208, 480, 600, 120 volt for high voltage applications only)
DDDD = current sensor rating: (100, 200, 400, 800, 1600, 3200, 25HV)
E = enclosure: J = metal (type 1), R = non-metallic (type 4X)
FF= protocol option:
G = Expanded Feature Package: package = X, no package = “blank”
SP = Single or Two Phase
HHH= Sensor Type: kit=split-core, scs= solid-core, non-supplied blank”
Brand Class Voltage Amperage Enclosure Communication Protocol Current Sensor/Option Current Sensor/Option Current Sensor/Option
Example E 34- 208 100- J 03 KIT
E34-208100-J03KIT
Brand E-Mon
Class 3400
Voltage 120, 208, 400 (380-415), 480, 600
Amperage
2HV, 100, 200, 400, 800, 1600, 3200
Enclosure
J (JIC Steel), I (Interior only), R (Rain tight)
Communication
Protocol
01 (EZ-7, EZ-7 ETHERNET),
02 (MODBUS RTU, EZ-7 ETHERNET),
03 (BACNET MSTP, EZ-7 ETHERNET),
04 (EZ-7, MODBUS TCP/IP),
05 (EZ-7, BACNET IP),
06 (MODBUS RTU, MODBUS TCP/IP),
07 (LONWORKS TP,EZ-7 ETHERNET),
08 (LONWORKS TP, MODBUS TCP/IP),
09 (EX-7, EZ-7 ETHERNET WITH MODEM),
10 (EZ-7, MODBUS TCP/IP WITH MODEM),
11 (EZ-7, BACNET IP WITH MODEM)
Current Sensors/
Options
-X- (EXPANDED FEATURE PACKAGE), KIT (Split Core),
SCS (Solid-Core), -SP (Single or Two Phase - 2 element)
