E-Tech S06-HAE - Machine Specifications; Model S06-HAE Specifications

OPERATOR’S MANUAL with Maintenance Information
Specifications
19
Model: S06-HAE
Height, working maximum
7.8 m
Height, platform maximum
5.8 m
Height, stowed maximum
Rails up
2.01 m
Height, stowed maximum
Rails lowered
1.83 m
Width
0.76 m
Length, platform retracted
1.86 m
Length, platform extended
2.76 m
Platform dimensions
(length × width)
1.67×0.74 m
Platform extension length
0.9 m
Maximum load capacity
230 kg
Maximum wind speed
12.5 m/s
Wheelbase
1.36 m
Turning radius (outside)
1.64 m
Turning radius (inside)
0 m
Ground clearance
9 cm
Ground clearance
Pothole guards deployed
1.6 cm
Weight
（See Serial Label）
Machine weights vary with option configurations
Controls
Proportional
AC outlet in platform
Standard
Maximum hydraulic pressure
(functions)
180 bar
System voltage
24 V
Tire size
Φ323×100 mm
Airborne noise emissions
<70 dB
Maximum sound level at normal operating
workstations (A-weighted)
Vibration value does not exceed 2.5m/s
2
Maximum slope rating,
Stowed position
25%
Maximum side slope rating,
Stowed position
25%
Note: Slope rating is subject to ground
conditions and adequate traction.
Maximum working slope
X-1.5°,Y-3°
Drive speeds
Stowed, maximum
4.0 km/h
Platform raised, maximum
0.6 km/h
Floor loading information
Tire load, maximum
710kg
Tire contact pressure
10.4kg/cm
2
1019kPa
Occupied floor pressure
1373kg/m
2
13.5kPa
Note: Floor loading information is approximate
and does not incorporate different option
configurations. It should be used only with
adequate safety factors.
Continuous improvement of our products is a
DINGLI policy. Product specifications are
subject to change without notice or obligation.
