OPERATOR’S MANUAL with Maintenance Information
Transport and Lifting Instructions
62
Observe and Obey:
√ Common sense and planning must be
applied to control the movement of the
machine when lifting it with a crane or
forklift.
√ Only qualified aerial lift operators should
move the machine on or off the truck.
√ The transport vehicle must be parked on a
level surface.
√ The transport vehicle must be secured to
prevent rolling while the machine is being
loaded.
√ Be sure the vehicle capacity, loading
surfaces and chains or straps are sufficient
to withstand the machine weight. See the
serial label for the machine weight.
√ The machine must be on a level surface or
secured before releasing the brakes.
√ Do not allow the rails to fall when the snap
pins are removed. Maintain a firm grasp on
the rails when the rails are lowered.
√ Do not drive the machine on a slope that
exceeds the slope or side slope rating. See
Driving on a Slope in the Operating
Instructions section.
√ If the slope of the transport vehicle bed
exceeds the maximum slope rating, the
machine must be loaded and unloaded
using a winch as described.
Brake Release Operation
For the Hydraulic Motor Drive Model
1 Chock the wheels to prevent the machine
from rolling.
2 Be sure the winch line is properly secured
to the drive chassis tie points and the path
is clear of all obstructions.
3 Push in the black brake release knob to
open the brake valve.
4 Pump the red brake release pump knob.
5 If you want to close the brake release, just
pull out the black brake release knob.
For the Electric Motor Drive Model
1 Chock the wheels to prevent the machine
from rolling.
2 Pull out the platform and emergency red
Emergency Stop button to the on position.
3 Turn the key switch to the ground
controller.
4 At the same time, long press the "Enter"
button on the ECU panel to enter the the
password input screen .
5 Press the “Menu enter button” 4 times to
enter the Menu screen .
6 Press the "up" or "down" button to switch
to the Special mode (" 4. Special Mode ")
7 Press the "Enter" button to display the
Special mode. Press the "up" or "down"
button to switch to the manual push menu
(" 1. Brake Release ")
8 Press "Enter" button to display "long press
to confirm release of brake". Long press
the "enter" button to show "Brake
