OPERATOR’S MANUAL with Maintenance Information
Specifications
30
Model: S1012-ACE
Height, working maximum
12 m
Height, platform maximum
10 m
Height, stowed maximum
Rails up
2.49 m
Height, stowed maximum
Rails folded
1.96 m
Width
1.15 m
Length, platform retracted
2.48 m
Length, platform extended
3.38 m
Platform dimensions
(length × width)
2.27×1.12 m
Platform extension length
0.9 m
Maximum load capacity
320 kg
Maximum wind speed
12.5 m/s
Wheelbase
1.87 m
Turning radius (outside)
2.2 m
Turning radius (inside)
0 m
Ground clearance
10 cm
Ground clearance
Pothole guards deployed
1.9 cm
Weight
（See Serial Label）
Machine weights vary with option configurations
Controls
Proportional
AC outlet in platform
Standard
Maximum hydraulic pressure
(functions)
240 bar
System voltage
24 V
Tire size
Φ381×127 mm
Airborne noise emissions
<70 dB
Maximum sound level at normal operating
workstations (A-weighted)
Vibration value does not exceed 2.5m/s
2
Maximum slope rating,
Stowed position
25%
Maximum side slope rating,
Stowed position
25%
Note: Slope rating is subject to ground
conditions and adequate traction.
Maximum working slope
X-1.5°,Y-3°
Drive speeds
Stowed, maximum
5.0 km/h
Platform raised, maximum
0.8 km/h
Floor loading information
Tire load, maximum
1310 kg
Tire contact pressure
12.9 kg/cm
2
1267.4 kPa
Occupied floor pressure
1258.4 kg/m
2
12.3 kPa
Note: Floor loading information is approximate
and does not incorporate different option
configurations. It should be used only with
adequate safety factors.
Continuous improvement of our products is a
DINGLI policy. Product specifications are
subject to change without notice or obligation.
