OPERATOR’S MANUAL with Maintenance Information
Control Panel
36
Platform Control Panel
1 Function enable switch
6 Drive function select button
2 Thumb rocker switch
7 Drive speed button
3 Proportional control handle
8 LED readout screen
4 Horn button
9 Red Emergency Stop button
5 Lift function select button
1 2 3 4 5 6 7
8
9
