E-Tech S06-HAE - Error and Fault Code Reference; List of Fault Codes and Reactions

OPERATOR’S MANUAL with Maintenance Information
Operating Instructions
52
Error indicator readout
The LED readout screen displays fault codes that provide information about the
machine operating status and about malfunctions. The fault codes listed in the
following charts describe malfunctions and can aid in troubleshooting the machine
by pinpointing the area or component affected.
List of Fault Codes
Display
Description
Lift Reaction
01
System Initialization Fault
Disables All Motion
02
System Communication Fault
Disables All Motion
03
Invalid Option Setting Fault
Disables All Motion
04
Calibration Fault
Warning Only
08
Key Switch Error
Disables All Motion
09
GPS Communication Fault
Warning Only
10
MC Communication Fault
Warning Only
11
BMS Communication Fault
Warning Only
12
Chassis Up or Down Switch ON
Disable Chassis Control
18
Pothole Guard Fault
Disable Lifting and Driving
31
31 Pressure Sensor Fault
Disables All Motion
32
32 Angle Sensor Fault
Disables All Motion
35
35 Pressure Sensor 2 Fault
Disables All Motion
36
36 Battery Drain Alarm
Drive speed limit
42
42 Platform Left Button ON
Warning Only
43
43 Platform Right Button ON
Warning Only
46
46 Platform Enable Button ON
Disable Platform Control
47
47 Joystick Not In Neutral
Drive speed limit
52
52 Drive Forward Coil Fault
Disable Lifting and Driving
53
53 Drive Reverse Coil Fault
Disable Lifting and Driving
54
54 Lift Up Coil Fault
Disable Lifting and Driving
55
55 Lift Down Coil Fault
Disable Lifting and Driving
