E-Z-GO SHUTTLE 2+2 Owner's Manual

Page 30
Owner’s Guide
GENERAL SPECIFICATIONS
RXV ELECTRIC - SHUTTLE 2 + 2 VEHICLE SPECIFICATIONS
** DO NOT use low inflation pressure tires on any E-Z-GO vehicle. DO NOT use any tire which has a recommended
inflation pressure less than the inflation pressure recommended in the Owner’s Guide.
BATTERIES Four 12 Volt deep cycle (70 minute minimum, 140 Amp-Hour discharge rate)
SPEED CONTROLLER Solid state, 230 Amp capacity
MOTOR 3 phase AC induction
TRANSAXLE 16.99:1 Reverse helical geared with input pinion splined to the motor shaft
BRAKES Motor brake controlled by the speed control unit and service brake pedal
PARKING BRAKE Automatic parking brake function
FRONT SUSPENSION Coil springs over hydraulic shock absorbers
REAR SUSPENSION Leaf springs with hydraulic shock absorbers
STEERING Single reduction rack & pinion
STEERING WHEEL Dual handgrips, scorecard holder & pencil holder
SEATING Foam cushion with vinyl cover and hip restraints/hand holds
SEATING CAPAPCITY Operator & 3 passenger
TOTAL LOAD CAPACITY 700 lbs. (318 kg) including operator, passenger, accessories & cargo
SPEED 14 - 17.5 mph (23 - 28.2 kph) in forward on flat ground
CHASSIS Welded tubular steel, powder coated (DuraShield™)
BODY
Flexible, Impact resistant, Injection Molded TPO (Thermoplastic Polyolefin)
with Base Coat / Clear Coat
STANDARD COLORS Ivory & Forest Green
DASH PANEL Scuff resistant plastic with 4 drink holders & storage for balls & tees
TIRES 18 x 8.5 - 8 (4 ply rated)**
TIRE PRESSURE 18 - 22 psi (124 - 152 kPa)**
GROUND CLEARANCE 4.5 inches (11.4 cm) at differential
WEIGHT 643 lbs (292 kg) without batteries
OPERATING CONTROLS &
INSTRUMENTATION
Removable key, ’deadman’ accelerator control, direction selector, audible
reverse warning, horn
LIGHTS Head lights, tail lights, brake lights
BATTERY CHARGER
Powerwise QE™ 48V, 110 - 120 VAC, fully automatic, line compensating, 13
Amp DC output at 48 Volts, 9.5 Amps input, 60 Hz anti-drive away charger/
vehicle interlock, UL Listed, CSA Certified
NOISE
VIBRATION, WBV
VIBRATION, HAV
Sound pressure; continued A-weighted equal to 68 db(A)
The highest RMS value of weighted acceleration is: 1.15 m/s
2
The highest RMS value of weighted acceleration is: less than 2.5 m/s
2
The uncertainty of mesurement is 0.2 m/s
2

E-Z-GO SHUTTLE 2+2 Specifications

General

Brand	E-Z-GO
Model	SHUTTLE 2+2
Category	Golf Cars
Language	English
