Eachine TYRO69 - Frame Kit Specifications; Motor Specifications

TYRO69
- 1 -
1.1 Frame kit
Axle Base: 105mm
Arm thickness: 2mm
Supporting maximum wheelbase: 2.5 inches
Spacing of mounting holes for supporting motors: 9mm
Material: 3K Carbon Fiber and TPU 3D Printing
2.1 Motor
Model: 1104/8600 kV
Groove Series: 9N/12P
Stator diameter: 11mm
Stator Height: 4mm
Axis Diameter: 1.5mm
Weight: 4.3G
Support supply voltage: 2-3s
Maximum power: 144W
Installation hole: M2
Installation hole spacing:9mm
