7. EXPLOSIVE VIEW 1
Item Part No. Description
203-1 CX-203-010000-0 Machine Body
231-2 CZ-231-080000-0 Pedal Front Cover
203-3 CX-231-020000-0 Left Cover
4 B-010-060101-0 Hex Socket Head Bolt M6×10
5 B-040-061412-1 Flat Washer 6*14*1.2
6 B-014-080251-0 Outer Hex Bolt M8x25
7 B-010-080201-0 Hex Socket Head Bolt M8×20
8 B-040-061412-1 Flat Washer 6*14*1.2
200-9 C-000-001020-0 Rubber Foot Buffer
200-10 C-200-500000-0 Bead Breaker Buffer
11 B-027-060401-0 Grounding Screw M6x40
12 C-200-580000-0 Lifting Lever
200-14 C-200-510000-0 Bead Breaker Arm Rubber
200-15 C-200-470000-0 Oil-Water Box
16 B-010-080201-0 Hex Socket Head Bolt M8x20
17 B-040-081715-1 Flat Washer 8*17*1.5
To Next Page
