4810 Clover Road • Greensboro, NC 27450 • 1-800-336-2776 • www.eagleequip.com • © Eagle Equipment 2018.01 • page 29
7. EXPLOSIVE VIEW 6
Item Part No. Description
200-504 C-200-320500-0 Gear Belt Pulley
601-MC S-050-220110-5 Motor 220V/50Hz
601-MY S-050-230075-0 Motor 220V
200-602 CX-200-330000-0 Motor Belt Pulley
603 B-007-080121-0
Hex Socket Head Bolt
M8×12
604 S-042-000686-0 Tire Changer Belt A-28
605 B-014-080651-0 Outer Hex Bolt M8x65
606 B-040-083030-1 Flat Washer 8X30x3
607-80 S-063-008000-0 Capacitor 80 F,110V
607-50 S-063-005000-0 Capacitor 50 F,220V
608 B-040-102020-1 Flat Washer 10X20x2
609 B-050-100000-0 Spring Washer 10
610 B-014-100251-0 Outer Hex Bolt M10x25
611 B-014-080351-0 Outer Hex Bolt M8x35
612 B-004-080001-0 Nut M8
613 B-040-082220-1 Flat Washer 8X22x2
614 C-200-560000-0 Motor Rubber Washer
200-615 CX-200-340000-2 Motor Support
616 CZ-000-205150-0 Motor Cable 5×1.0
617 B-050-080000-0 Spring Washer 8
200-618 C-200-560000-0 Motor Rubber Buffer
To Next Page
