7. EXPLOSIVE VIEW 10 KEY
Item Part No. Description
F5001 B-010-120401-0
Hex socket head bolt
M12X40
F5016 B-014-100601-0
Outer hex bolt
M10X16
F5002 B-040-122520-1 Flat washer 12X24X2
F5017 B-001-100001-0 Self lock nut M10
F5003 Spring washer /12
F5018 CX-099-040102-0 Base
F5004 B-010-100401-0
Hex socket head bolt
M10X40
F5019 B-001-100001-0 Self lock nut M10
F5005 B-040-102020-1 Flat washer 10
F5020 B-010-100401-0
Hex socket head bolt
M10X40
F5006 B-050-100000-0 Spring washer 10
F5021 Thrust handle
F5007 B-010-060201-0
Hex socket head bolt
M6X20
F5022 C-200-580000-0 Lifting lever
F5008 B-040-061210-1 Flat washer 6
F5023 CZ-099-040104-2 Tire pressing ruler
F5009 Spring washer 6
F5024 B-010-100251-0
Hex socket head bolt
M10X25
F5010 CX-005-020000-B
Tire pressing arm
bottom plate
F5025 CX-005-030000-B Tire pressing arm 005B
F5011 Flat washer 12
F5026 B-001-160001-0 Self lock nut M16
F5012 CX-099-040101-0 Column
F5027 CX-005-050000-B Tire pressing arm pin
F5013 CX-005-010200-B Raise-fall sleeve
F5028 CX-036-050000-0 Connection bolt
Item Part No. Description
F5014 C-005-120000-0 Raise-fall cylinder
F5029 B-001-160001-0 Self-lock nut M16
F5015 CX-200-230000-0 Locking handle
F5030 C-008-090100-0
Tire pressing head
(upper)
F5031 CX-005-040000-B
Tire pressing arm
connector
F9007 S-035-060040-1 Air hose (PU)6*4
F9017 S-035-060040-1 Air hose (PU)6*4
F9018 CX-005-200000-0
Raise-fall switch
baseboard
F9019 B-017-040301-0
Cross- at head screw
M4*30
F9020 B-024-050161-1
Cross round head
screw M5*16
F9021 S-012-010406-0 Quick union 1/4-6
F9022 S-030-010818-0
Handle valve
4H230L-08
F9023 B-004-040001-1 Nut M4
F9024 S-035-060040-1 Air hose (PU)6*4
F9025 S-015-000006-3 T-union 3-6
F9026 S-035-060040-1 Air hose (PU)6*4
F9027 S-023-010801-0 Mufe1/8
F9028 C-007-181000-0 Control valve cover
F9030 B-017-040161-0
Cross- at head screw
M4*16
