6. Illustrations & Parts List
Main Parts & Components (Continued)
Description
Part Number
Qty
1
Gear Shaft
1
2
Main Motor Combination
1
3
Left Guide Rail
1
4
Sliding Plate
1
5
Extension Spring (x2)
2
6
Left Knife
1
7
Oblique Gear Shaft
1
8
Right Guide Rail
1
9
Middle Knife
1
10
Bearing
16002
1
11
Right Knife
1
12
Spacing Sleeve
1
13
Right Wallboard
1
14
Roller Wallboard
1
15
Roller
1
16
Bearing
608
1
17
Eccentric Shaft
1
18
Bearing
6900
4
19
Sub Post
1
20
Roller Frame
1
21
Sealing Board
1
22
Swing Block
1
23
Extension Spring Hanging Board
1
24
Strap Guide Plate
1
25
Cover Plate
1
26
Strap Guide Plate
1
27
Sleeve
1
28
Staff
1
29
Circular Clip
D=12
1
30
Circular Clip
D=10
1
31
Eccentric Shaft
1
32
Bearing
16001
2
