Eagle 1000A - Page 28

- 28 -
5.1 Illustration
Base (continued)
Name
Part Number
Qty
1
Turntable
FG-023
1
2
Pedestal
FG-7000AG
1
3
Roller Wheel Assembly (1)
-
4
4
Roller Wheel Assembly (2)
-
8
5
Large Chain Wheel
FG-008
1
6
Bearing
51213
7
Bearing
6009
8
Travel Switch Module (1)
FG-009
1
9
Count Travel Switch
TZ-918
1
10
Tension Chain Wheel
FG-021
2
11
Tension Wheel Seat
FG-011
1
12
Chain
12A
1
13
Elastic and Tension Wheel Seat
FG-012
1
14
Motor Cover Fix Part (2)
FG-376B
1
15
Motor Base
1010.80.10.PL
1
16
Motor
YS7124/B14
1
17
Reducer
NMRV050
1
18
Motor Covering Plate
FG-374B
1
