Eagle 1000A - Specifications

- 6 -
1.2 Specifications - Eagle 1000A
Power Supply
110VAC, 60Hz
Turntable Speed
0-10 RPM
Turntable Diameter
59”
Turntable Diagonal
80”
Turntable Height
3.125”
Pre-Stretch Motor
n/a
Pre-Stretch Gear Ratio
n/a
Pre-Stretch Chain
n/a
Film Stretch
Manually Adjustable on Carriage
Max Film Height
87”
Mast Height
94”
Max Turntable Weight Capacity
3,300 lbs
Max Package Height (2” Overlap)
76.75”
Machine Dimensions
80.7” x 65” x 96.85”
(L x W x H)
Shipping Weight
1,433 lbs
Attachment
Ramp or Custom Heavy Duty
3
Noise
≤75db
Environment
Humidity ≤98% Temperature 32-104°F
1
Note: Black product requires custom photo-eye installation.
2
Factory ramp is for use with hand pallet jacks only. Maximum combined weight of jack and product must not
exceed 1,300lbs. Custom heavy-duty ramps are available for use with loads exceeding 1,300lbs.
3
Turntable maximum RPM can be increased to 20 RPM upon request.
