Eagle 1000A - Page 32

- 32 -
5.4 Illustration
Mast (continued)
Name
Part Number
Qty
1
Mast Cover Plate
FG-389B
1
2
Mast Cover Braket
FG-388B
1
3
Reduction Gear Bearing Base
FG-398B
1
4
Carriage Motor
YS6334/B14
1
5
Reducer
NMRV040/60-
1
6
Motor Shaft
FG-390B
1
7
Drive Sprocket
FG-060
1
8
Carriage Bolts
-
-
9
Chain
08B
2
10
Slide Way
FG-393B
2
11
Support Iron Box
FG-392B
2
12
Sliding Block
-
4
13
Sliding Block Base
-
2
14
Electric Base Plate
FG-333AGB
1
15
Column Gate
FG-399B
1
16
Left Column
FG-385B
1
17
Drive Chain Wheel
FG-061
1
18
Drive Shaft
FG-059
1
19
Column Bottom Plate
FG-394B
1
20
Column Bottom Plate
FG-387B
3
21
Right Column
FG-386B
1
22
Column Front Cover Plate
FG-373B
1
23
Lift Frame
FG-370B
1
