Eagle 1000A - Page 35

- 35 -
5.5 Illustration
Carriage – Continued from previous page.
Name
Part Number
Qty
1
Motor Cover
FG-123
1
2
Pre-Stretch Motor
NMRV040/20-
YS6334-B14
1
3
Pre-Stretch Motor Base Plate
FG-111C
1
4
Bearing Block
FG-132
3
5
Pre-Stretch Roller
FG-114
1
6
Straining Ring
FG-138A
1
7
Tightening Screw
M10
1
8
Film Positioning Plate
FG-135A
2
9
Film Bearing
FG-134
1
10
Micro Switch Frame
1060.180.1.PL
1
11
Location Pallet
FG-2526
1
12
Transition Roller
FG-115
5
13
Transition Roller Block
FG-112
1
14
Pressure Spring
FG-131
2
15
Locating Pin
FG-126A
2
16
Key 1
6x6x60mm
1
17
Rail
FG-124
1
18
Bearing
6901
10
19
Key 3
5x5x14mm
2
20
Chain
06B
1
21
Drive Chain Wheel
FG-144
1
22
Drive Sprocket
FG-143
1
23
Lower Hinge
FG-128
1
24
Hinge Pin
FG-129
2
25
Hinge Axis
FG-118
1
26
Master Rotor
FG-113
1
27
Lift Body
FG-110A
1
28
Stretch Spring
01-162
1
29
Micro Switch Module
FG-121
1
30
Micro Switch
Z-15GQ22-B
1
31
Asperities
40×δ2×3300mm
2
32
Optoelectric Switch
205234
1
33
Left/Right Link Block
FG-120A
2
34
Protective Frame
FG-140A
1
35
Transition Drum Shaft
FG-116
3
