Eagle 1000A - Page 37

- 37 -
5.6 Illustration
Carriage – Continued from previous page.
Name
Part Number
Qty
1
Hand Shank
FG-164A
1
2
Eccentric Gear
FG-163
1
3
Indicator Block
FG-167
1
4
Tension Block
FG-161
1
5
Tensioning Block Shaft
FG-162
1
6
Adjustment Shank
FG-158
1
7
Bracket
FG-159
1
8
Tightening Screw
M10
1
9
Retaining Ring
FG-138A
1
10
Film Locating Plate
FG-135A
2
11
Film Shaft
FG-134
1
12
Roller
FG-153II
1
13
Pre-Stretch Shaft
FG-152
1
14
Positioning Pallet
FG-2526
1
15
Roller Shaft
FG-154II
1
16
Detent Ring
FG-155
2
17
Non Pre-Stretch Shroud
FG-157
1
18
Eccentric Gear Frame Bracket
FG-165A
1
19
Fine Adjustment Block
FG-168
1
20
Top Shaft Base
FG-156
1
21
Bearing
16007
2
22
Top Cover
FG-151
1
23
Spring
FG-160
1
24
Belt
M-L105
1
25
Non Pre-Stretch Belt Steel Ring
FG-239
1
26
Lift Body
FG-150
1
27
Bearing
61904
2
28
Protective Frame
FG-170A
1
29
Protective Frame Shaft
FG-141
1
30
Internal Thread Ball
M8
1
31
Micro Switch Frame
1060.180.1.PL
1
32
Micro Switch
MQS-216
1
33
Transition Roller Outer End Cap
A50-106.1
2
34
Bearing
6002
2
35
Transition Roller Inner End Cap
A50
2
